ATEN KVM Extender CE840A, USB true 4K HDMI

Maximum resolution: 4096 x 2160 @ 60 Hz

Maximum distance: 100 meters (328 feet)

USB ports: 9 total (including USB-B for PC connection)

HDMI ports: 3 total

Network ports (RJ-45): 4 total

RS-232 ports: 2 (DB-9)

Form factor: 19" rack mountable

Video resolution: Supports True 4K (3840 x 2160 @ 60 Hz 4:4:4 and 4096 x 2160 @ 60 Hz 4:4:4) with HDR10+

Distance: Up to 100 meters (328 feet) over a single Cat 6A cable with no compression and zero latency

HDBaseT 3.0: Allows transmission of HDMI, audio, RS-232, Ethernet, and USB signals over one cable

Audio Support: Compatible with LPCM 7.1CH, Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio

USB Expansion: Each device (local and remote) has 4 USB 2.0 ports – 2 for keyboard/mouse and 2 for other peripherals

Dual Console Operation: Allows control from both sides via USB keyboard, mouse and HDMI monitor

RS-232 and Ethernet: Support for serial communication and network connectivity

HDCP Compatibility: Compatible with HDCP 2.3 and 2.2

ESD Protection: Built-in electrostatic discharge protection (8KV contact, 15KV air)

Firmware: Firmware upgradeable
