New
Motherboard ASUS ROG STRIX Z890-H GAMING WIFI, LGA 1851
Ref. number: ASUS-MB-ROG-Z890-H-WF
available
View availability
Шереметя
New
Motherboard ASUS ROG STRIX Z890-H GAMING WIFI, LGA 1851
available
View availability
Шереметя
Ref. number: ASUS-MB-ROG-Z890-H-WF
Client
w/ VAT
w/ VAT
Online leasing
|
monthly payment
|
monthly payment |
|
|---|---|---|
| 3 payments |
|
- |
| 6 payments |
|
|
| 9 payments |
|
|
| 12 payments |
|
|
| 15 payments |
|
|
| 24 payments |
|
|
Fast and secure delivery
14 day return policy
The ROG STRIX Z890-H GAMING WIFI is a high-performance motherboard designed for Intel Core™ Ultra Series 2 processors on the LGA 1851 socket. It features DDR5 memory support, Wi-Fi 7 connectivity, and PCIe 5.0 x16 for next-generation GPUs.
Key Features:
- Advanced AI Technologies: AI Overclocking, AI Cooling II, AI Networking II, and ASUS AI Advisor.
- Powerful Performance: 16+2+1+2 80A power stages for stable power delivery.
- High-Speed Connectivity: Wi-Fi 7, USB 20Gbps Type-C (30W PD), 5Gb LAN, and multiple M.2 slots.
- Optimized Cooling: Large heatsinks, high-conductivity thermal pads, and an L-shaped heatpipe.
- DIY-Friendly Design: Q-Release PCIe slot, M.2 Q-Latch, BIOS FlashBack, and pre-mounted I/O shield.
| Manufacturer | ASUS |
| Warranty | 36 months |
| Product code | 90MB1K20-M0EAY0 |
| Barcode | 4711387880678 |
| CPU Socket |
1851
|
| Chipset |
Intel Z890
|
| CPU supports |
Intel® Core™ Ultra Processors (Series 2)
|
| Memory Standard |
DDR5
|
| Maximum Memory Supported |
256 GB
|
| Number of Memory Slots |
4
|
| Frequency Memory |
8600(OC) MHz
|
| Support Dualchannel |
Yes
|
| Integrated Audio |
Supports up to 32-Bit/192 kHz playback
High quality 120 dB SNR stereo playback output and 113 dB SNR recording input
Realtek ALC1220P 7.1 Surround Sound High Definition Audio CODEC
|
| Integrated LAN |
1 x Realtek 5Gb Ethernet
|
| Integrated Wi-Fi |
Bluetooth v5.4
2x2 Wi-Fi 7 (802.11be)
|
| PCI-E x16 |
1 x PCIe 5.0 x16 slot
|
| PCI Express x4 |
1
|
| PCI-E x1 |
1
|
| PCI-E slots | |
| Interface Serial ATA |
4 x SATA3 6.0 Gb/s
|
| M2 socket |
M.2_4 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 & SATA modes)
M.2_1 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 5.0 x4 mode)
M.2_2 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode)
M.2_3 slot (Key M), type 2280/22110 (supports PCIe 4.0 x4 mode)
|
| Raid support |
0, 1, 5, 10
|
| Power Connector |
1 x 24-pin Main Power connector
1 x 8-pin +12V Power connector
2 x 8-pin +12V Power connector
|
| Connectors |
1 x HDMI port
1 x Display Port
1 x RJ-45
1 x optical S/PDIF Out connector
2 x Аudio jacks
1 x BIOS Flashback Button
2 x SMA antenna connectors
1 x Clear CMOS button
|
| USB Ports |
4 x USB 5Gbps ports Type-A
4 x USB 10Gbps ports Type-A
2 x USB 20Gbps ports Type-C
|
| Dimension |
ATX - 30.5 x 24.4 cm
|
| Other |
256 Mb Flash ROM, UEFI AMI BIOS
|
| Weight | 1.224 kg |
